N-TET

FC-FDJ-200 UAV Engine

Product Overview
Displacement
200CC
Power
20HP/7500rpm
Main applications
aero-engine power systems for large-displacement two-stroke engine platforms and related aviation propulsion scenarios.
FC-FDJ-200 UAV engine with displacement 200CC, power/performance 20HP/7500rpm.

Product Introduction

FC-FDJ-200 is a 200CC two-stroke aero engine with belt drive and electric starting.

Technical Specifications

ParameterDescription
Typetwo-stroke
Bore55mm
Stroke42mm
Displacement200CC
Power20HP/7500rpm
Compression ratio10:1
Reduction ratio1:2.7
Drive modebelt
Starting modeelectric starter
Net weight (without exhaust pipe)10.3 Kg
Simple exhaust pipe weight1.1 Kg
Enhanced exhaust pipe weight2.2 Kg
Spark plugDLE-8A
Gasoline93#、97#
Power output14V 1A
Optional power output14V 4A
Propeller1220mm
